SH-3000-OHA

Designed for easy, lightweight, portability, and powerful suction to remove dust and fiber contaminants from welding, cutting, grinding, or removal operations. Highest efficiency removal down to 99.97% at 0.3 micron size particles.

Description

Filter Media:

Clark Air Systems utilizes the longest life, lowest maintenance filters available:

1st Stage:
Multi-ply, depth loading, pre-filters with tackified media. These 45% efficient filters catch the bulk of the particles generated from cutting, grinding, or removal operations.

2nd Stage:
90-95% ASHRAE efficiency pleated media catches fine dust particles, rated at 95% removal of particles 1 micron or larger

Optional 2nd Stage:
99.97% DOP certified HEPA filter with gasket seal to meet strictest codes. 99.97% removal of 0.3 micron particles.

Maintenance:
Replacement of filters periodically. Only a few minutes are required to replace any filter. The frequency depends on conditions. Magnehelic filter gauge is to monitor filter resistance.

Cabinet:
The units are constructed with 16 gauge welded steel. Hinged, gasketed door allows easy access to all stages of filtration. The entire unit is finished with a corrosion resistant baked-on powder coating. The welded steel handles are also powder coated. The unit is portable with industrial grade locking casters.

Unit Specs:

  • Air Flow Capacity: 1600 cfm
  • Amp Draw: 115 volt, 60 hz = 6.3 amps
  • Unit Weight: 285 pounds
  • Unit Dimensions: 40″W x 27″D x 28″H
  • Motor: 3/4 Horsepower, TEFC motor, 1750 RPM, with backward incline SWSI Corrosion proof blower wheel
  • Arm: 8″x10ft standard, also available in 6″ diameter and 14ft lengths
